In the dense and intricate world of modern electronics, providing reliable, serviceable, and space-efficient overcurrent protection is paramount. This is the critical role of the PCB mount fuse holder. Designed to be soldered directly onto a printed circuit board, these components provide a secure and reliable connection point for a replaceable fuse, right at the heart of the electronics. From simple, low-profile fuse clips to fully enclosed, shock-safe blocks, the choice of holder impacts everything from manufacturing efficiency to field serviceability. At GFEFUSE, we specialize in engineering a high-integrity PCB mount fuse holder for every application, ensuring a stable foundation for onboard circuit protection in the most demanding electronic designs.

Get A Quote

Deep Industry Focus

Established in Dongguan since 2013, we have remained wholly dedicated to electronic protection devices, integrating R&D, manufacturing, and sales to guarantee superior performance and reliability.

Comprehensive Portfolio

Our lineup spans fuses, fuse holders, fuse boxes, automotive fuses, DC fuses, high-voltage fuses, new-energy fuses, and related accessories—serving consumer electronics, automotive, power equipment, telecom, and new-energy sectors.

Dual-Market Success

Products have rapidly gained domestic market share while also being exported worldwide, earning broad international recognition and popularity.

Continuous Innovation

A specialized R&D team and sustained technology investment drive ongoing product innovation, expanding coverage and accelerating time-to-market.

Certified Quality

UL, cULus, TÜV, CE, CQC approvals and full RoHS & REACH compliance underscore our commitment to quality and customer confidence.

about us

We Have The Best Solutions for Your Business

Founded in 2013 in Dongguan, Guangdong, our company is a professional manufacturer ofelectronic protection devices. For years, we have been focusing on the protection device field, withan integrated team for development, production and sales, committed to providing customers withproducts of perfect performance and reliability.

Dur moin products include, fuses, fuse ho ders, fuse boxes, outomotive fuses, gutomotive fuse holders, Dcfuses, high-voltage fuses, new energy fuses ond other peripherol occessories, These products ore widelyused in multiple fields such os consumer electronics, outomotive electronics, power equipment,communicotion systems ond new energy. Aiming ot stoble performonce ond reliobility, our products hove notonly guickly won recognition in the domestic morket but olso been exported overseos, enjoying wide morketpopulority.

As 0 competitive compony in the protection device industry, we hove been committed to technologicol R&Dinvestment, quipped with 0 professionol R&D teom, we continuously promote product innovotion to ensureour wide product coveroge ond occelerote morket opplicotion speed of our products.

We olways toke quolity os our core goal and strive to be customer-oriented. Our products hove obtoined UL
cULus, Tuv, CE, COC ond other product certificotions, ond ore in complionce with ROHS ond REACH directives.

Learn More

"How to save space on a crowded PCB design?"

You are designing a compact electronic device and every square millimeter of board space is precious. The problem is that a standard horizontal fuse holder can take up a lot of room. There are two great solutions for this. First, consider a vertical PCB mount fuse holder, which stands the fuse up to dramatically reduce the footprint. Second, consider very low-profile PCB fuse clips. GFEFUSE offers both of these space-saving PCB mount fuse holder options to help you meet the demands of your power-dense design.

"My fuse holder gets hot and the solder is melting."

This is a very dangerous situation. The problem is not the fuse; it's high resistance in the holder itself. This is almost always caused by a low-quality PCB mount fuse holder with weak clips that don't maintain enough pressure on the fuse caps. This poor connection generates heat, which can melt the solder and even damage the PCB. The only solution is to replace the faulty component with a high-quality holder. A GFEFUSE PCB mount fuse holder uses high-spring-force materials to ensure a tight, cool-running connection that prevents this failure.

"Can I use a PCB mount holder for an automotive circuit?"

While you can, it requires careful consideration. The problem is that the automotive environment has extremely high levels of vibration and shock, which can be a challenge for board-mounted components. The best solution is to use a through-hole PCB mount fuse holder rather than an SMD type, as the through-hole pins provide a much stronger mechanical anchor to the board. Furthermore, selecting a high-quality GFEFUSE PCB mount fuse holder with high clip tension is crucial to ensure the fuse itself does not vibrate loose over time, making it a viable option for stable, onboard automotive electronics modules.

"How do you add a replaceable fuse to a circuit board?"

You are designing a PCB and need to include a fuse that can be easily replaced if it blows. The problem is you need a reliable method to connect it to the board. The standard solution is to use a PCB mount fuse holder. This component is soldered directly to the board and provides a socket for the fuse. You can choose from simple fuse clips or fully enclosed blocks. GFEFUSE manufactures a wide variety of high-quality PCB mount fuse holder options, allowing you to easily and reliably integrate serviceable protection into your electronic design.

User Reviews

What users say about GFEFUSE

These fuses solved our long-standing over-current headaches; zero failures since installation, UL certs eased compliance audits, and the technical team’s rapid support cut our downtime by half.

Alice

The wide product range eliminated sourcing chaos; one-stop fuse and holder kits arrived fast, all REACH-compliant, and the field engineers praised their consistent performance under harsh automotive loads.

Brian

High-voltage DC fuses from this firm ended our solar inverter burnouts; precise trip curves protect panels without nuisance blows, and the RoHS label streamlined our green certification process instantly.

Carlos

Switching to their automotive fuse boxes removed warranty claims; vibration-proof design survives rough roads, while the online configurator shaved days off our design cycle and delighted the OEM client.

Diana

New-energy fuses arrived pre-tested, cutting our qualification time by weeks; sales team sent 3D files overnight, and the low-profile holders saved precious PCB space for extra battery cells.

Ethan
Frequently Asked Question

Do you have any question?

GFEFUSE is a trusted manufacturer because we engineer every PCB mount fuse holder with superior materials, such as high-conductivity, spring-grade phosphor bronze for our clips and high-temperature, UL 94V-0 rated plastics for our housings. This ensures a reliable, low-resistance connection and the highest level of safety for your electronic designs.

Key considerations include the voltage and current rating of the holder, ensuring it can handle the circuit's power. You must also consider the physical footprint, the required fuse size (e.g., 5x20mm, 6.3x32mm), and the required "creepage and clearance" distances on your PCB layout around the holder to maintain proper insulation.

You would choose a fully enclosed or "shock-safe" PCB mount fuse holder when user safety is a primary concern. These holders have a body and a cap that completely insulate the fuse, preventing operators from accidentally touching any live electrical parts, which is often a requirement to meet safety agency standards like UL or CE.

PCB fuse clips are the simplest form of PCB mount fuse holder. They are individual metal clips that are soldered to the board to hold the ends of a cartridge-style fuse (like a 5x20mm glass fuse). They are low-cost and have a very low profile, but they do not offer any insulation or protection from accidental contact.

A through-hole PCB mount fuse holder has leads or pins that go through holes in the circuit board and are soldered on the opposite side, providing a very strong mechanical bond. An SMD (Surface Mount Device) holder sits on top of the board and is soldered to pads on the same side, which is ideal for automated, high-volume manufacturing.

PCB mount fuse holder is a component that is soldered directly onto a printed circuit board (PCB) to provide a socket for a replaceable fuse. It allows for circuit protection to be integrated at the board level, making it easy to replace a blown fuse without desoldering components.
